Pressure Grit blasting cabinet works on the direct pressure principle of blasting. When high abrasive velocity produces by pressure Grit blaster results in completing the job at a faster rate. A pressure container bolted under a hopper of a Grit blaster cabinet for automatic abrasive media refilling systems. For the high efficiency of dust collection, a tubular fabric bag dust collector, with a generous filter area is attached with the blaster cabinet as a standard feature.
A manual shaker is provided for shaking. A high-Pressure Grit blaster cabinet is prescribed for fast cleaning, removal of corrosion, and heavy rust using coarse abrasives. All types of coarse and medium-sized abrasive media can be used depending on the application.
Pressure Blast System, where the abrasive is placed in the pressure vessel and is sealed then. The vessel is pressurized with the same pressure as the blast hose is, which is attached at the bottom of the pressure vessel. The abrasive mix is put into the blast hose and compressed gases carry it through the Grit blast nozzle towards the surface. It is also a dry process.
Pressure Grit blasting Cabinet Available in three standard models:
| Model | APB - 9182 | APB - 12090 | APB - 150120 |
| Working Chamber (mm) | |||
| Height | 775 | 900 | 900 |
| Weight | 910 | 1200 | 1500 |
| Depth | 820 | 900 | 1200 |
| Door Opening (mm) | |||
| Weight | 730 | 800 | 1100 |
| Height | 675 | 800 | 800 |
| Overall Dimension (mm) | |||
| Height | 2130 | 2030 | 2080 |
| Weight | 1100 | 1365 | 1665 |
| Depth | 2500 | 2430 | 2730 |
| Dust or Mist Collector or Reclaimer Fan Motor HP |
1.0 | 1.0 | 1.5 |
| Fan Capacity (M /min) | 14.16 | 14.16 | 22.66 |
| Fan Capacity (CFM) | 500 | 500 | 800 |
| Filter Cloth Area (M ) | 7.5 | 7.5 | 10 |
| Blast Nozzle (mm) | 5,6 | 5,6 | 5,6 |
| Abrasive Storage Capacity Litres (CFT) |
28(1.0) | 42(1.5) | 42(1.5) |
| Weight in Kg (appro.) | 580 | 650 | 760 |
| Abrasive Feed | Direct Pressure | Direct Pressure | Direct Pressure |
